Akdeniz Dedektör
LÜTFEN FİYAT SORUNUZ!
İhtiyaca özel talep üzerine edildiğinden stoklarda bulunmaz.
Mala ProEx GPR Kurulum Videosu:
ÖNEMLİ NOT: MALA ÜRÜNLERİNİN TÜRKİYE TEK YETKİLİ BAYİSİ Dedektorburada.com'dur.
Mala ProEx GPR Paket İçeriği:
ProEx Kontrol Ünitesi
ProEx Modülü-Optical
Li-Ion Batarya Paketi
Li-Ion Batarya Şarj Cihazı
Veri Kabloları
ProEx Servis Kiti
Kontrol Ünitesi Manuel İşletimi
Taşıma Çantası
Kullanım Kılavuzu
Kontrol Ünitesi için Sırt Çantası
PC Tutucu Aksesuarı
Ground Vision II İşletim Yazılımı
Shielded Anten ve Aksesuarları
100-800 MHz Shielded Anten Elektronik Seti
250 MHz Shielded Anten ve Taşıma Çantası
Anten Çekme Kolu ve Mesafe Ölçüm Tekerleği
MONİTÖR:
RAMAC Monitor XV11
Yazılımlar:
REFLEXW 2D&3D GPR Veri-İşlem Yazılımı
MALÅ GPR ProEx System
The MALÅ Professional Explorer (ProEx™) System is a modular, full-range Ground Penetrating Radar (GPR) system designed to meet the needs of the advanced professional user. At the heart of this system is the MALÅ ProEx Control Unit. Designed on a completely new technical platform, the MALÅ ProEx is the most versatile control unit in the MALÅ Geoscience range and replaces the World famous RAMAC/GPR CUII as the new high-end full range system.
GPR offers a practical, reliable and most importantly non-destructive solution for subsurface geophysical and geotechnical investigations.
The MALÅ ProEx Control Unit is fully compatible with broad range of antennas from MALÅ Geoscience and offers a flexible and versatile approach to detecting subsurface targets and geological layers accurately, efficiently and in real-time.
MALÅ Geoscience’s modular design approach offers you a flexible and affordable choice to system configuration.
You need only to invest in what you need today; however, as your needs change, so can your MALÅ GPR system.
Main Applications
Whatever your application is, the MALÅ ProEx can assist in providing solutions to your subsurface investigation needs in areas such as:
• Archeology & Forensics
• Borehole
• Concrete NDT & Civil Engineering
• Environmental
• Geological/Mining
• Ice & Snow Measurements
• Research
• Road & Transportation
• Utility Detection & Mapping
• And more!
Specific Features
MALÅ Geoscience is renowned for its innovative designs and the tradition continues with this third-generation digital control unit. The MALÅ ProEx boasts a list of practical features rolled into one rugged design suitable for advanced and professional users.
• Modular Design
• Dual hardware channel (4 data channels)
• Multi-channel: max. 8 antennas (16 data channels) as optional
• Supports all antennas from MALÅ Geoscience
• Supports array configurations
• Ethernet communication
• Pulse Repetition Frequency (PRF): 100 KHz (upgradeable)
• 100 KHz PRF per hardware channel
System Configuration
The MALÅ ProEx is a modular digital radar control unit with multi-channel functionality; the base designed for two hardware channels (4 data channels). This allows connection of two separate antennas for simultaneous data collection whilst also providing a third "virtual antenna”.
By adding optional expansion units, the system can be expanded to eight hardware channels (16 data channels) to operate up to eight individual antennas. A choice of three antenna modules (optical, high frequency and coax) allows the user to connect any MALÅ antenna in various configurations, for single, dual or multi-antenna operation. Thus enabling a wide range of advanced measurements to be carried out.
Technical Specification
Power supply: Li-Ion 12V battery
Operating time: 5 h nominal, pending on configuration
Operating temp: -20° to +50°C / 0° to 120 °F
Environmental: IP67
Dimensions (cm): 32.5 (h) x 22.2 (w) x 4.2 (d)
Weight: 1.9 kg
Antennas: The MALÅ ProEx is fully compatible with the entire range of MALÅ antennas, the MALÅ XV Monitor data acquisition platform and Windows based MALÅ GroundVision¹ acquisition software.
Not: Yukarıdaki bilgi ve açıklamalar üretici firma verileridir.
